Product features

• ? 7 inch color touch screen;

• ? Support multi language, convenient for different users;

• ? Built in environment automatic detection program, automatically detect the test environment and remind users;

• ? Built in international standard grade parameters, easy and fast operation;

• ? EUT intelligent detection;

• ? Self calibration function to ensure the normal operation of the equipment;

• ? Built in 1000x differential probe and 1000x current probe;

• ? With breakdown current monitoring function, the product breakdown automatically alarms and stops the test;

• ? Rs232/usb interface, which can be controlled by PC and print test report.

Product parameters

• Product model:


  Surge waveform


  Open circuit voltage


  short-circuit current


  Surge polarity


  Phase angle


  Output impedance


  Coupling / decoupling network


  Surge coupling mode


  frequency


  Interval time


  Working power supply


  ambient temperature

• SUR S6


  Voltage wave: 1.2/50 us; Current wave: 8/20 us


  0.2~6kV


  0 .1 ~ 3kA


  Positive / negative, alternating positive and negative


  0~359 ° synchronous or asynchronous


  2q (common mode 12q2)


  Built in, single-phase three wire, 16A


  Differential mode 18uf, common mode 9uf /10q


  1~9999 times


  10 ~9999s


  AC220V 50/60Hz


  15 ℃~35 C

Product recommendation

Impulse current generator sur 10kA

Model：SUR 10KA

The lightning surge generator sur 10kA is used to inspect the anti surge protection devices such as zinc oxide arrester valve piece, varistor, SPD, TVs tube, gas discharge tube, etc. for surge impact test. The product produces 8/20us surge pulse waveform, and the technical indicators of the waveform comply with the provisions of national standards and IEC standards.

Learn more

Impulse current generator sur 20KA

Model：SUR 20KA

The lightning surge generator sur 20KA is used to inspect the anti surge protection devices such as zinc oxide arrester valve piece, varistor, SPD, TVs tube, gas discharge tube, etc. for surge impact test. The product produces 8/20us surge pulse waveform, and the technical indicators of the waveform comply with the provisions of national standards and IEC standards.

Learn more

Three phase 5kV pulse group generator EFT T4

Model：EFT T4

In the circuit, such as from the switching transient process (cutting off inductive loads, bouncing relay contacts, etc.), it will usually interfere with other electrical and electronic equipment in the same circuit. This kind of interference is characterized by high amplitude, short rise time, high repetition rate and low energy. Clusters of narrow pulses can charge the junction capacitance of semiconductor devices, which may cause circuit or equipment errors when accumulated to a certain extent. The burst generator determines a common reproducible evaluation basis for evaluating the performance of power supply ports, signal, control and grounding ports of electrical and electronic equipment when disturbed by electrical fast transient bursts. The products meet the requirements of new standards such as iec61000-4-4, en60100-4-4 and gb/t17626.4.

Learn more
